AdmiN TS-15''





Plug & Play Touch screens can also work without a setup program. Suitable for connection to a PC or POS system.

Particularly robust, response time of 5ms, with a USB port for connecting the touch system that makes the connection easy and fast on all systems. 4: 3 aspect ratio and 1024 x 768 / 60HZ screen resolution.

 Specification
  • Panel Size 15" TFT LCD.
  • Display Ratio 4:03
  • Resolution 1024×768/60HZ.
  • Color 16.7M colors
  • Pixel Pitch (mm) 0.264H*0.264V mm
  • Input VGA
  • Contrast 1000:01:00
  • View Angle H170/170 V160/160
  • Response Time 5ms
  • Life (hrs) 50000 Hours










  • Material Plastic Case
  • Installation Desktop Stand / Standard VESA Holes
  • Touch Interface USB
  • Touch Screen 5 Wire Resistive Touch Screen
  • OSD power,menu,auto,up,down
  • Menu Language English, Germany, French, Spanish, Russian and Others
  • Power Supply 110-250 V AC / 12V DC, 50-60 Hz
  • Power Consumption 25W
  • Line frequency 30-80KHZ
  • field frequency 56-75HZ
  • Operating condition: Temperature:-10-60 degrees Celsius ; Humidity:20-80%
  • Storage condition: Temperature: -20 to +70 degrees Celsius; Humidity: 10%-90%
  • Touch validity >50,000,000
  • Certificate CE RoHs FCC
  • Weight(Net/Gross): 3.98kg / 4.5 kg
  • Package (L/W/H): 430*101*397mm , 5 sets per carton
